JZJ200 auto splicer

characters:

• Applicable maximum base paper diameter: 1500mm.

With the automatic tension control of the base paper holder, the paper can be connected at high speed with high success rate.

The paperless tail joint reduces the loss of base paper (the overlap of base paper is only 40mm as wide as the tape).

When the paper receiving car is moved out, it will automatically rotate out, and the paper loading is easy. The automatic tension control will ensure zero paper receiving error.

All PLC automatic control, accurate action, less fault, convenient maintenance.

When the buffer wheel pulls the paper for the first time, it is automatically aligned and easy to pull the paper.

The advantages of the machine: the cylinder controlled paper feeder will not break tiles and blister under the control of ordinary motor at high speed.

The maximum paper pick-up speed is 200m / min.
