GM30 gluing machine

Structural feature：

The glue machine is a corrugated paper conveyed from the flyover. After preheating, it is coated again with glue and then pasted into the double-sided machine to paste and bond to produce three-layer five-layer cardboard.

Frame cast iron structure, stable performance, upper middle layer preheater diameter 400mm, increase paper temperature to facilitate glue paste, double pressure roller design glue evenly, stainless steel glue groove, automatic circulation glue supply.

after quenched of the glue roller surface,the hole machining, surface grinding and doing balancing engraved anilox pit type, coating evenly, less consumption of plastic.

The transmission of the glue unit is directly connected by the frequency conversion motor through the reducer, and the frequency conversion control ensures that the linear speed of the glue roller is synchronized with the double-sided machine and can operate independently. Use angle sensor, PLC, touch screen man-machine interface display. According to different paper quality, different speeds automatically control the amount of glue, according to the different corrugated shape automatically adjust the gap between the pressure rollers, without accumulating errors.
