FY-D thin blade slitter scorer

Product Attributes

Width: 1400 - 2800 mm.

Speed: 300m/minute

Structural feature:

The synchronous servo motor controls the row of knives and wires. Automatic reset. Precise size. Change order time is1-3seconds.

PLC control system, using CANopen bus system, with order management function, equipped with a synchronous signal input interface with dryer speed.

HMI with 10.4-inch color touch screen, storage 999 orders, change orders automatically or manually for a single, fault alarm.

Three kinds of pressure line forms：Convex against the concave（three layers line）、Convex against the concave（five layers line）、Convex against Flat，Three kinds of electric pressure line forms can be converted.Crimping round shades by computer control，linear, and easy to bend.

Using thin tungsten alloy steel knife，sharp blade，long life of more than 8 million meters.

knife sharpener for computer control，automatic or manual knife sharpener，Cutting edge sharpening can be divided,improve productivity Efficiency.

Imported synchronous belt transmission is adopted, and the thin blade holder and the crimping seat are supported by linear bearings, and the positioning size is accurate without accumulating errors.

The cutting and crimping are driven by independent frequency conversion motors. The suction port is automatically positioned with the change order.

With gas storage tank and low pressure protection function.
