Technical upgrading of carton machinery equipment

According to thbservation of the current Carton Machinery, the structure of the processing equipment for the subsequent process of most carton machinery is relatively aging, the performance is poor, and the pressing and printing effects are not ideal; The speed of changing products is slow, the production efficiency is low, and the operation and maintenance are not convenient, which is not suitable for the development needs of carton processing industry. www.chinacartonmachine.com

1、 The carton machine changes the original chain and manual paper feeding mechanism into the chain automatic paper feeding mechanism. The original chain paper feeding relies on manual paper feeding on the paper feeding table one by one. The disadvantages of this paper feeding method are high labor intensity of operators, low paper feeding efficiency and poor accuracy. After the chain automatic paper feeding mechanism is changed, the paperboard is stacked on the paper feeding table, and the automatic paper feeding is implemented, which not only reduces the labor intensity of the operator, but also improves the efficiency and accuracy of paper feeding.

2、 The original phase manual adjustment mechanism is changed to manual zero adjustment and automatic zero adjustment. The adjustment speed is slow, the number of trial adjustments is many, and the waste of cardboard is also many. Xinglong carton machinery adopts zero adjustment, which not only improves the adjustment speed, but also makes the operation more convenient. In theory, the paperboard should be the finished product, which greatly saves the trial machine paperboard.

3、 Carton machinery improves the adjustment method of slotting knife and crimping wheel. The old ordinary model adjusts the knife and crimping wheel one by one. There are eight upper and lower knife discs, eight crimping wheels and four slitting knives, which need to be adjusted 20 times. This method is improved to manual linkage tool adjustment and automatic linkage tool adjustment. With this mechanism, as long as one cutter head is adjusted, the upper and lower cutter heads and upper and lower thread pressing wheels will move in linkage, and the tool adjustment speed is increased many times, which is particularly suitable for multi variety and small batch processing.

4、 Change the original semi-automatic ink circulation into manual automatic circulation and pneumatic automatic circulation. The original semi-automatic circulation is the ink circulation when starting up, and the ink cannot be circulated when stopping. This will easily cause the ink to dry up on the anilox roller, blocking the mesh and affecting the printing effect. After changing to manual automatic circulation and pneumatic automatic circulation, the above situation can be avoided and the printing effect can be greatly improved.

Through the improvement of pressing line and slotting of carton machinery, the effect of pressing line and slotting can be improved, and the service life of slotting knife can be extended. After the above improvements, not only the production efficiency, service performance and product transformation speed have been improved, but also the appearance of the equipment has been greatly improved, and the manufacturing cost has not increased much. If standardized, serialized and modular design and production are adopted, the manufacturing cost will be reduced and the quality will be improved. If all carton equipment manufacturing Co., Ltd. make efforts in this regard, the technical level of carton machining equipment in China will be further improved.
