Production Management System of Corrugated Cardboard Production Line

(1) Automatic paper feeder

Automatic paper feeder is used to connect paper, avoiding unnecessary waste in paper feeding, reducing the shutdown and quality problems of corrugated board production line, ensuring stable high production speed and high quality of the whole production line.

(2) Tungsten Carbide Corrugated Roller

As the heart of single-sided machine, corrugated roll plays a decisive role in the quality of corrugated cardboard, and has a direct impact on the economic efficiency of cattle production. Tungsten carbide corrugated roll is a special technology which uses thermal spraying technology to melt tungsten carbide alloy powder and spray it on the tooth surface of corrugated roll to form tungsten carbide coating. Its service life is 3-6 times longer than that of ordinary corrugated roll. The corrugated height of the roll is almost unchanged throughout its service life, which ensures the smooth quality of corrugated cardboard, reduces the consumption of corrugated core paper and paste by 2%-8%, and reduces the production of waste products. www.chinacartonmachine.com

Thirdly, paster contact rod

The contact bar of pasting machine is made up of many wear-resistant arc plates and springs. The spring elasticity always makes the arc plates adhere to the pasting rolls evenly. Even if the pasting rolls are worn and depressed, the spring plates will also be depressed along with the depressed, and the corrugated core paper will always be evenly adhered to the pasting rolls. In addition, the spring with elastic balance can automatically adjust the height of corrugated core paper according to the thickness of base paper and the change of corrugated shape, so that the corrugated height of corrugated core paper when it is pasted into the paster and when it is pasted out of the paster after pasting can be guaranteed to remain unchanged, the amount of glue coating can be effectively controlled and the quality of cardboard can be greatly improved.

(4) Hot plate contact plate

The hot plate contact plate is used to replace the traditional gravity roll contact heat transfer mode. It is made of special wear-resistant material sheet board, each sheet board is equipped with spring with elastic balance, so that each sheet can be fully touched on the hot board, increase the heating area of the board, improve the heat transfer efficiency, so as to improve the speed, ensure the integrity of the corrugated type, enhance the strength of the corrugated board and increase the thickness of the corrugated board, paperboard does not degum, do not foam, adhere. Good, reduce the waste rate.

Automatic pasting system

Paste making process is the most volatile process in the whole production process and the most critical process to affect the quality of cardboard. The traditional pasting formulation is single, which is easy to cause inaccurate feeding due to human factors and make the quality of the adhesive unstable. The automatic pasting system is a typical synthesis of technology, machinery and automatic control. It can deal with the formulation function, historical data, real-time data, dynamic monitoring function and man-machine dialogue in the pasting system. The pasting quality is stable and controlled, which can make the production line operation more stable, reduce human factors, and completely solve the quality of paperboard foaming, corrugating and softening. Problem, Reduce Waste Rate
