The important role of the chain components in the cprrugated carton machine

The important role of the chain components in the cprrugated carton machine
In a carton machinery and equipment in the chain is a critical part of the performance of the chain to a large extent depends on the front and rear axles and the installation of the chain wheel is not accurate. The requirement is that the parallel degree of the front and rear axle is less than 1/300. The front and rear wheels are in the 0.5 - 1.0mm/ M. If the chain is in the process of operation found that the above problems should be adjusted in a timely manner. www.chinacartonmahine.com
The reason is the chain chain jitter load is too large or too loose, and has a plurality of link is not flexible. The solution is device chain tension device or adjustable center distance. The reason is that the noise is too large, the sprocket is not coplanar; the chain is too large or too small; lubrication is insufficient; chain and sprocket wear; or chain pitch is too large. The solution is: to view the front and rear axle parallel with the sprocket and to correct the situation. To adjust the center distance and the tensioning device, so that it can obtain the appropriate tightness and ensure the lubrication to the workpiece.


The chain wheel is mounted on the shaft and should not be tilted and swing. In the same transmission components in the end of the two sprocket should be located in the same plane, the chain wheel base is 0.5 meters below the allowable error of 1 mm; sprocket base distance of 0.5 meters or more, allowing error 2 mm. However, there is no conflict between the chain gear side of the phenomenon, if the two wheels are too easy to take off the chain and to speed up the wear and tear, the need to pay attention to view and adjust the offset.
