Carton laminating machine features

Carton laminating machine features
1, paper feeding machine adopts stepless speed device, adapt to different paper feeding. The precision of the limelight, the operation of the operation is very convenient to adjust the limelight in the relative position of the paper stack. Special non stop continuous paper device to ensure continuous production. www.chinacartonmachine.com
2, the host hard chromium composite roller built-in heating system and automatic temperature control device, the uniform temperature distribution. Large diameter composite drum design, to ensure stable operation of the OPP film, not about displacement. Hand pressure hydraulic cylinder control composite pressure, can make the next two drum pressure balanced force. High precision chrome plated heating roller with high performance pressure rubber roller, the perfect realization of hot laminating process.
3, Taiwan "C.jin 's" hydraulic pressure for auxiliary control system to keep the film edge in a straight line, stable and accurate.


4, coating oil head adopts imported stepless governor control, more effective to maintain the quantity of coating stability, coating and hard chromium roller high measurement precision manufacturing to ensure the quantity of coating is uniform, accurate coating effect. At the same time as standard two sets of pump and stainless steel tank, the use of water-based and oil-based glue suitable. The DC motor film coating device, stable, rapid and simple operation.
5, the film roll adopts magnetic powder brake, stable tension, special pneumatic membrane device of adhesive film lamination film, to ensure the tightness of the fault prevention of roll film.
6, automatic cutting, cutting length can be set according to the size of paper free unit linkage operation system, with the speed of the host, automatic change, simple operation, saving labor costs, reduce the labor intensity of the operator. Cutting machine disc type rotary blade cutter, rotary knife block, 4 sets of blades, can be fine adjustment control, easy to operate; adjust, with the pressure roller interaction, according to the size of the paper, can freely control the speed.
7, the drying system adopts the design of horizontal drying box special and automatic temperature control system (heating speed, save the auxiliary time work from 30 degrees to 90 degrees 15 minutes or so), this design can make the OPP film steady running dry, will not lead to offset or shrink film. The drying system, which is suitable for the water glue glue, has high heat and wide distribution. The heat energy is evenly distributed on the OPP film, and the glue is quickly dried and the reaction rate is fast.
8, advanced circuit using Panasonic original PLC control, motor with variable frequency control, stable, energy saving, safe and reliable
