Improvement of carton machining equipment

At present, the structure of most carton machinery processing equipment in the next process is aging, the performance is poor, and the pressing and printing effects are not ideal; The product transformation speed is slow, the production efficiency is low, and the operation and maintenance are not convenient, which is not suitable for the development needs of the carton processing industry.

1、 Change the original chain and manual paper feeding mechanism to the chain automatic paper feeding mechanism. The original chain paper feeding is manually placed on the paper feeding table one by one. The disadvantages of this paper feeding method are high labor intensity, low paper feeding efficiency and poor accuracy. After the chain automatic paper feeding mechanism is changed, the paperboard is stacked on the paper feeding table to implement automatic paper feeding, which not only reduces the labor intensity of the operator, but also improves the efficiency and accuracy of paper feeding. www.chinacartonmachine.com

2、 The original phase manual adjustment mechanism is changed to manual zero adjustment and automatic zero adjustment. The adjustment speed is slow, the number of trial adjustments is large, and the waste of cardboard is also large. After the zero adjustment, not only the adjustment speed is improved, but also the operation is more convenient. Theoretically speaking, the paper board should be the finished product and greatly save the trial machine paper board.

3、 Improve the adjustment method of slotting cutter and crimping wheel. The old ordinary model adjusts the cutter and crimping wheel one by one. There are eight upper and lower cutter heads, eight crimping wheels and four slitting cutters, which need to be adjusted 20 times. This method is improved to manual linkage tool adjustment and automatic linkage tool adjustment. With this mechanism, as long as one cutter head is adjusted, the upper and lower cutter heads and the upper and lower thread pressing wheels will move in linkage, and the tool adjustment speed is increased by many times, which is particularly suitable for multi variety and small batch processing. 4、 Change the original semi-automatic ink circulation into manual automatic circulation and pneumatic automatic circulation. The original semi-automatic circulation means that the ink circulates when the machine is turned on, and the ink cannot be circulated when the machine is turned off. This is easy to cause the ink to dry up on the anilox roller, blocking the mesh and affecting the printing effect. After changing to manual automatic circulation and pneumatic automatic circulation, the above situations can be avoided and the printing effect can be greatly improved.

By improving the crimping and slotting, the crimping effect and slotting effect can be improved, and the service life of the slotting cutter can be prolonged. After the above improvements, not only the production efficiency, service performance and product transformation speed have been improved, but also the appearance of the equipment has been greatly improved, and the manufacturing cost has not increased much. If standardized, serialized and modular design and manufacture are adopted, the manufacturing cost will be reduced and the quality will be improved. If all carton equipment manufacturing Co., Ltd. make efforts in this regard, the technical level of carton machining equipment in China will be further improved
