Carton machine lubrication five fixed management

First, according to the equipment lubrication parts, designated person responsible for maintenance and lubrication.

1, each class daily lubrication once or several points, and all sliding rail surface, etc., by the operator responsible for refueling and maintenance.

2, fuel tank, oil tank, oil supplement and regular cleaning, oil change, etc., are responsible for the lubricating workers, operators cooperate.

3, all kinds of equipment box, oil tank, hydraulic oil pump gear box, box, box, the storage capacity of the operator shall be responsible for the observation of oil below the marking shall be responsible for timely to reflect the lubrication, lubrication by responsible for add and implement regular oil plan. Where the tank needs cleaning before disassembly, the repairman shall be responsible for the cleaning of the tank. www.chinacartonmachine.com

4, carton equipment on the electrical components, such as a variety of transmission motors, etc., should be responsible for electrical cleaning, oil change.

Two, timing: according to lubrication chart or card provisions, regular, regular refueling, oil and oil cleaning.

1 、 equipment operators check the oil level of each tank before they go to work every day, clean each slide rail surface, add lubricating oil, and inspect the empty running before production, and observe whether the lubrication system is working properly.

2. According to the lubrication chart of the equipment, check the parts according to the class, day, week and month intervals, or refuel.

Three, fixed-point: set out the lubrication points of each part of the equipment, according to different lubrication requirements, color separation mark.

The provisions of the 1, all kinds of lubricating parts in equipment, and is equipped with lubrication oil hole and an oil cup, nozzle, oil pump, oil tank and other refueling device belong to the fixed range.

2, lubrication workers and operators must remember the equipment lubrication parts, lubrication points, and can skillfully and correctly use these lubrication refueling device.

Four, quality: for each lubrication point, according to different requirements, determine the varieties of oil grades.

1, in strict accordance with the provisions of the lubrication card for the use of oil, but when the provisions of the oil shortage, and need to substitute or mixed use, should be implemented in accordance with the regulations.

2, oil shall be tested and analyzed before use, and shall not be used for unqualified oil.

3, all the tank and fuel tank on the equipment should be kept intact, the cover should be lost in time to fill, so as to avoid iron filings, dust and so on into the friction surface and fuel tank.

Five, quantitative: determine the oil content, oil content, daily consumption and oil recovery in each part.

1, equipment oil should be formulated "consumption quota", operators and lubricating workers should be in accordance with "quota" oil.

2, enterprises, workshops, workshops, teams and teams and a single station
