Working principle and technology of carton die cutting machine

The working principle of carton die cutting machine is the use of steel, metal molds, steel wire (or steel plate carved into the template), applying certain pressure by stamping version, printing or cardboard rolling cut to shape. If the printing press into a single graphic product called die-cutting; use steel wire in the printing press or left traces of angled slot called indentation; if the use of the Yin and Yang of the two block template, through to the mold is heated to a certain temperature, pattern or font with stereoscopic effect on the printing surface is called hot stamping out if you use a substrate; complex called attached to another substrate; in addition to exclude genuine outside the rest part called waste; above can be collectively referred to as die-cutting technology. www.chinacartonmachine.com

The cutting process is a process of the most commonly used packaging printing to the cutting knife is used according to the requirements of product design drawings into the die, under pressure, will print or other wire-o blank forming process of rolling cut into the required shape or cut marks. Creasing process is to use a knife or a wire pressing mold, through the pressure on the sheet extrusion line, or the line roller at a predetermined position in plate bending forming. Usually indentation is the process of cutting knife and wire cutter in the same mould and process for the simultaneous cutting and indentation processing on the die-cutting machine, referred to as die-cutting. The main process of indentation process was as follows: to adjust the pressure to determine the rules to paste, pressure die cutting, substrate materials, waste removal, formal die-cutting rewinder or cut piece, the number of packages.
