Characteristics of Thin Blade Slitter Scorer

Characteristics of Thin Blade Slitter Scorer

The thin blade slitter scorer is a paper splitter, but the blades used are very thin. Its characteristic is that the incision is full during cutting, without damaging the ripples at the incision. The full name of the thin blade slitter scorer is the thin blade longitudinal cutting machine, which belongs to the carton machine for cardboard box processing. Due to the use of an alloy thin blade, the paper is cut without burrs, and the pressing line is neat, with a generally fast speed. Especially widely used in post-press processing carton machine, combined with thin blade slitter scorer, it has the following main application characteristics in practical applications:

1. A thin blade slitter scorer is used to cut indentations. After grinding with a grinding wheel, the blade is sharp, making the edges of the cut cardboard smooth and slightly flat, improving the appearance quality and overall quality of the cardboard, especially in the future feeding of cardboard printing, reducing waste and improving the quality of the cardboard box.

2. The knife sharpening can switch between manual and automatic modes, and the sharpening and stopping times can be selected based on the time and cardboard running speed. Keep the blade sharp and make the cut cardboard smooth and tidy.

3. The thin blade slitter scorer adopts a single blade independent lifting structure, which can be switched according to the number of cardboard cutting times. The cutting width and pressing line width can be manually adjusted, and the size of the blade caused by different wear processes can be adjusted at will.

4. Use the front pre pressing roller to feed the paper (lower rubber roller), then cut it, pull the paper over the rubber shaft, and then press the line with the pressing roller (lower rubber roller) to make the indentation clear and deep. The cutting is driven by an alloy paper cutting machine and an active blade synchronous belt, which can be quickly switched when changing blades.
